EN13240 EN16510 Certified Cast Iron Stove (Tango) – Ecodesign Compliant

Category Stove Brand: Fireway

Additional information

Power	7KW
Chimney diameter	140 mm
Chimney outlet	Top or rear
Clean combustion system	Yes
Furnace location	Wall
Furnace material	Cast iron grade SCH20
Glass door	Yes
Heating volume	140 m3
Depth	389 mm
Height	862 mm
Width	389 mm

Product Description

The Tango cast iron stove is a compact and stylish heating solution designed for efficient
space heating in residential interiors. With a nominal output of 7 kW, it is capable of
heating rooms up to 150 m³ while maintaining stable and comfortable warmth.
Manufactured from high-quality chromium cast iron and lined with vermiculite inside the
combustion chamber, Tango ensures durability, high thermal efficiency, and long heat retention.
Its large glass door offers an excellent view of the flame, making it both a functional and
decorative element for modern and traditional interiors.

Key Features

EN13240 and EN16510 certified, fully Ecodesign compliant
Nominal heating power of 7 kW
High efficiency of 75%
Durable cast iron body (grade SCh20)
Vermiculite-lined firebox for improved combustion
Clean glass air-wash system for clear flame view
Top and rear flue outlet options
Suitable for wood logs and fuel briquettes
Compact footprint with elevated legs for better airflow
Sealed firebox with precise air control for primary and secondary combustion

Technical Specifications

Heating Power	7 kW
Efficiency	75%
Heated Volume	Up to 150 m³
Heated Area	Approx. 70 m²
Fuel Type	Wood logs, briquettes
Maximum Log Length	35 cm
Material	Cast iron (SCh20)
Firebox Lining	Vermiculite
Flue Diameter	140 mm
Flue Connection	Top and rear
Dimensions (W × D × H)	389 × 389 × 862 mm
Weight	112 kg
Installation Position	Freestanding
Glass Door	Yes

Installation and Usage Guide

The Tango stove can be installed with either a top or rear flue connection, providing flexibility
for various room layouts. Installation must comply with local building regulations and chimney
standards. Ensure adequate clearance from combustible materials and proper ventilation.

Use only seasoned wood or approved fuel briquettes. Adjust primary and secondary air controls to
regulate combustion intensity and maintain optimal efficiency. Regular cleaning of ash and
inspection of the chimney are recommended for safe operation.

Customer Reviews

“Compact size, excellent heat output, and beautiful flame view.”
“Easy to install and very efficient for a small living room.”
“Solid cast iron quality and stable performance during long burning cycles.”

Frequently Asked Questions (FAQ)

What type of fuel can be used?

The stove is designed for natural firewood and compressed fuel briquettes.

Is the stove suitable as a main heating source?

It is ideal for small to medium rooms and can also serve as a secondary or backup heat source.

Does it comply with European standards?

Yes, the Tango stove complies with EN13240, EN16510, and Ecodesign requirements.

Can the flue be connected from the rear?

Yes, both top and rear flue connections are supported.
