| Height | 1032 mm |
|---|---|
| Width | 486 mm |
| Depth | 506 mm |
| Heat output | 10 kw |
| Chimney diameter | 150 mm |
| Chimney outlet | Top and back |
| Clean combustion system | Yes |
| Furnace material | Cast iron grade SCH20 |
| weight | 180 kg |
| Heating room area (square meters) | 100 ㎡ |
Nominal power: 10 kW, peak power up to 12 kW. Heating volume depends on room configuration and insulation type.
| Specification | Details |
|---|---|
| Power | 10 kW |
| Heating volume | 200–250 m³ |
| Heating area | 100 m² |
| Depth | 506 mm |
| Width | 486 mm |
| Height | 1032 mm |
| Weight | 180 kg |
| Flue diameter | 150 mm |
| Flue outlet | Top & Rear |
| Combustion chamber material | Vermiculite |
| Body material | Cast iron (SCh20) |
| Glass thickness | 4 mm |
| Air intake control | Yes |
| Efficiency (COP) | 82–83% |
| Color | Black |
