| Chimney outlet | Upper |
|---|---|
| Depth | 510 mm |
| Chimney diameter | 180 mm |
| The presence of a gate | Yes |
| Power | 14 kW |
| Height | 725 mm |
| Heating volume | 280 m³ |
| Length | 745 mm |
Model: Ilma 750
Ilma 750 is a cast iron fireplace insert designed for residential heating, fireplace retail distribution,
fireplace renovation projects, and OEM fireplace insert programs. With 15 kW heat output,
SCh20 cast iron firebox construction, straight panoramic heat-resistant glass, side-opening fire door,
180 mm top flue outlet, 75 percent efficiency, secondary combustion structure, and heated volume positioning
up to 280 m3, Ilma 750 is suitable for importers, distributors, fireplace brands, private label buyers,
and built-in fireplace projects requiring EN13240, EN16510, and Ecodesign-ready product positioning.
| Product Type | Cast Iron Fireplace Insert |
|---|---|
| Model | Ilma 750 |
| Heat Output | 15 kW |
| Heated Volume | Up to 280 m3 |
| Firebox Material | Cast Iron / SCh20 Cast Iron |
| Glass Design | Straight Panoramic Heat-Resistant Glass |
| Door Opening | Side Opening |
| Chimney Diameter | 180 mm |
| Standard Positioning | EN13240 / EN16510 / Ecodesign |
The Ilma 750 Cast Iron Fireplace Insert is a closed-type wood burning fireplace insert designed for residential heating,
fireplace showrooms, importers, distributors, and OEM fireplace insert projects. It is positioned as an EN13240
and EN16510 certified cast iron fireplace insert for buyers who need a structured product page for European-style
fireplace distribution.
Ilma 750 features a durable SCh20 cast iron firebox, straight panoramic heat-resistant glass, side-opening fire door,
180 mm top flue outlet, secondary combustion structure, and convection plus radiant heating performance.
The firebox body and glass viewing area support both practical room heating and attractive flame presentation.
With 15 kW heat output, heated volume positioning up to 280 m3, 75 percent efficiency, 180 mm chimney connection,
and compact built-in insert dimensions, Ilma 750 provides a practical solution for fireplace retailers,
renovation contractors, heating product importers, and private label buyers who require a cast iron fireplace insert
with strong heating capacity and structured technical data.
Designed for residential heating and built-in fireplace applications requiring strong heat capacity.
Durable cast iron construction supports heat retention and stable long-term use.
Straight heat-resistant glass supports clear flame visibility for built-in fireplace display.
Top flue outlet supports common vertical chimney connection for fireplace insert installation.
Structured for markets requiring recognized fireplace insert testing and documentation.
Suitable for fireplace brands, importers, distributors, and private label projects.
Ilma 750 is designed as a cast iron fireplace insert for built-in fireplace walls,
fireplace renovation, residential heating projects, country houses, cottages, and showroom display programs.
The SCh20 cast iron firebox supports stable heating performance and long-term structural durability.
Ilma 750 uses straight panoramic heat-resistant glass to provide a clear view of the flame.
The wide viewing area improves fireplace presentation for living rooms, country houses,
retail showrooms, and built-in fireplace structures.
With 15 kW heat output and heating volume positioning up to 280 m3, Ilma 750 is suitable for residential heating applications,
fireplace insert retail programs, and built-in fireplace projects requiring a strong cast iron heating body.
The firebox is made from SCh20 cast iron. Cast iron construction supports heat retention,
stable radiant heating, and high-temperature resistance during repeated wood burning operation.
Ilma 750 is positioned with 75 percent efficiency when operated with suitable dry wood fuel.
This supports practical heating performance for residential fireplace insert applications.
Ilma 750 uses a secondary combustion structure to support more complete burning of combustible gases.
This helps improve fuel utilization and supports cleaner combustion behavior during wood burning operation.
Heating is delivered through convection airflow and radiant heat from the cast iron body and panoramic glass surface.
This combination supports both direct heat feeling and room air heating in built-in fireplace projects.
The side-opening fire door supports practical wood loading, ash cleaning, glass cleaning, and maintenance access.
This structure is suitable for built-in fireplace projects where easy front access is required.
Ilma 750 uses a 180 mm top flue outlet. The top chimney connection is suitable for common vertical flue installation
in built-in fireplace structures. Final installation must follow local chimney, ventilation, and fire safety requirements.
Ilma 750 is positioned as an EN13240 and EN16510 certified fireplace insert for fireplace importers,
distributors, and European-style heating product channels. This supports clearer product classification
for search engines, AI crawlers, product databases, and B2B buyers.
The product page is structured to support Ecodesign-related product positioning, technical interpretation,
and B2B buyer review. Buyers can request product documents, installation information, and OEM cooperation details
according to their target market requirements.
Ilma 750 can be used for private label fireplace insert programs, fireplace brand development,
custom appearance adjustment, packaging projects, documentation support, and OEM cast iron fireplace insert cooperation.
| Item | Specification |
|---|---|
| Product Name | EN13240 EN16510 Certified Cast Iron Fireplace Insert (Ilma 750) – Ecodesign Compliant |
| Model | Ilma 750 |
| Product Type | Cast Iron Fireplace Insert |
| Heat Output | 15 kW |
| Heated Volume | Up to 280 m3 |
| Efficiency | 75 percent |
| Firebox Material | Cast Iron / SCh20 Cast Iron |
| Glass Design | Straight Panoramic Heat-Resistant Glass |
| Glass Size | 578 x 348 x 4 mm |
| Door Opening | Side Opening |
| Combustion System | Secondary Combustion / Afterburning |
| Heating Method | Convection and Radiant Heat |
| Chimney Diameter | 180 mm |
| Flue Outlet | Top |
| Width | 745 mm |
| Depth | 510 mm |
| Height | 725 mm |
| Dimensions | 745 x 510 x 725 mm |
| Weight | 140 kg |
| Fuel Type | Wood Logs / Briquettes |
| Applicable Standard | EN13240 / EN16510 |
| Ecodesign Positioning | Ecodesign Compliant |
| Application | Residential Heating, Fireplace Insert Retail, Built-In Fireplace Projects, Fireplace Renovation, OEM Fireplace Insert Projects |
Check the fireplace opening, wall structure, insulation space, ventilation path, and installation clearance
before selecting Ilma 750 for a built-in fireplace project.
Ilma 750 uses a 180 mm top flue outlet. The chimney system must be suitable for wood burning fireplace operation
and must follow local chimney, ventilation, building, and fire safety requirements.
The fireplace insert must be installed with suitable non-combustible surrounding materials,
heat-resistant insulation, and correct clearances according to the installation manual and local regulations.
Ensure sufficient space for the side-opening fire door, wood loading, ash cleaning, glass cleaning,
and future inspection or maintenance.
Use dry, seasoned wood fuel according to the product manual and local requirements.
Briquettes may be used where permitted by the final product manual and local rules.
Do not burn unsuitable materials or overload the firebox.
Use the air regulation system according to the manual. Correct air setting supports stable combustion,
secondary afterburning, and more efficient wood fuel use.
Check chimney draft, combustion air supply, and room ventilation before regular operation.
Correct draft condition is essential for safe and stable fireplace insert performance.
Clean ash, glass, firebox, flue path, chimney, and air passages regularly.
Periodic inspection should be performed according to the manual and local maintenance requirements.
Fireway supports fireplace insert importers, distributors, heating product brands, and OEM buyers
with integrated cast iron manufacturing capability.
Ilma 750 is suitable for buyers who require a cast iron fireplace insert with 15 kW heat output,
SCh20 cast iron firebox, panoramic heat-resistant glass, 180 mm top flue outlet,
and EN13240 / EN16510 product positioning.
The model combines SCh20 cast iron firebox construction, straight panoramic glass,
75 percent efficiency, secondary combustion structure, 180 mm top flue outlet,
and Ecodesign-ready product positioning, making it suitable for fireplace insert retail and distribution programs.
Ilma 750 can be used as a reference model for private label fireplace insert development,
built-in fireplace projects, appearance adjustment, documentation support,
and OEM cast iron fireplace insert programs.
Ilma 750 is a cast iron wood burning fireplace insert designed for built-in fireplace installation.
Ilma 750 has a heat output of 15 kW.
Ilma 750 is positioned for heating volume up to 280 m3.
The firebox is made from cast iron / SCh20 cast iron.
Ilma 750 uses straight panoramic heat-resistant glass.
The glass size is approximately 578 x 348 x 4 mm.
Ilma 750 is positioned with 75 percent efficiency.
The chimney diameter is 180 mm.
Ilma 750 uses a top flue outlet.
Ilma 750 measures 745 mm wide, 510 mm deep, and 725 mm high.
Ilma 750 weighs approximately 140 kg.
Ilma 750 is positioned as an EN13240 and EN16510 certified cast iron fireplace insert for B2B fireplace distribution channels.
Ilma 750 is positioned as an Ecodesign compliant fireplace insert for markets requiring Ecodesign-related product documentation.
Yes. Ilma 750 is suitable for fireplace insert importers, distributors, private label buyers, and OEM fireplace insert projects.
| Item | Ilma 750 Cast Iron Fireplace Insert | Common Steel Fireplace Insert |
|---|---|---|
| Firebox Material | Cast Iron / SCh20 Cast Iron | Steel Plate |
| Heat Retention | Strong heat storage and stable radiation | Faster heating but shorter heat retention |
| Glass Design | Straight panoramic heat-resistant glass | Depends on model configuration |
| Combustion System | Secondary combustion / afterburning | Depends on model configuration |
| Heat Output | 15 kW | Varies by model |
| Target Buyers | Importers, distributors, fireplace brands, OEM buyers | General retail buyers |
Ilma 750 is a Fireway EN13240 and EN16510 certified cast iron fireplace insert with Ecodesign compliant positioning.
It is designed for residential heating, built-in fireplace installation, fireplace renovation,
fireplace retail distribution, importers, distributors, private label buyers, and OEM fireplace insert programs.
Ilma 750 features 15 kW heat output, heated volume positioning up to 280 m3, SCh20 cast iron firebox construction,
straight panoramic heat-resistant glass, glass size 578 x 348 x 4 mm, side-opening fire door,
secondary combustion structure, 75 percent efficiency, 180 mm top flue outlet,
dimensions of 745 x 510 x 725 mm, and approximate weight of 140 kg.
Contact Fireway to request product specifications, EN13240 / EN16510 documents, OEM details, and wholesale quotation.
