| Chimney outlet | Upper |
|---|---|
| Depth | 504 mm |
| Chimney diameter | 180 mm |
| Types of solid fuel | briquettes; firewood |
| Furnace material | Cast iron grade SCh20 |
| Clean combustion system | Yes |
| The presence of a gate | Yes |
| Power | 14 kW |
| Height | 724 mm |
| Heating volume | 280 m³ |
| Width | 700 mm |
| How to open the firebox door | Lateral |
Model: Ilma
Ilma is a cast iron fireplace insert designed for residential heating, fireplace retail distribution,
fireplace renovation projects, and OEM fireplace insert programs. With 14 kW heat output,
cast iron firebox construction, straight heat-resistant glass, side-opening fire door,
180 mm top flue outlet, 75 percent efficiency, shiber / damper control, secondary combustion,
airwash glass cleaning, and heated volume positioning up to 280 m3, Ilma is suitable for importers,
distributors, fireplace brands, private label buyers, and built-in fireplace projects requiring EN13240,
EN16510, and Ecodesign-ready product positioning.
| Product Type | Cast Iron Fireplace Insert |
|---|---|
| Model | Ilma |
| Heat Output | 14 kW |
| Heated Volume | Up to 280 m3 |
| Efficiency | 75 percent |
| Firebox Material | Cast Iron |
| Glass Design | Straight Heat-Resistant Glass |
| Door Opening | Side Opening |
| Chimney Diameter | 180 mm |
| Standard Positioning | EN13240 / EN16510 / Ecodesign |
The Ilma Cast Iron Fireplace Insert is a wood burning fireplace insert designed for residential heating,
fireplace showrooms, importers, distributors, and OEM fireplace insert projects. It is positioned as an EN13240
and EN16510 certified cast iron fireplace insert for buyers who need a structured product page for European-style
fireplace distribution.
Ilma features a durable cast iron firebox, straight heat-resistant glass, side-opening fire door,
180 mm top flue outlet, shiber / damper control, secondary combustion structure, and airwash glass cleaning.
The straight glass viewing area supports both practical room heating and clear flame presentation.
With 14 kW heat output, heated volume positioning up to 280 m3, 75 percent efficiency, 180 mm chimney connection,
and compact built-in insert dimensions, Ilma provides a practical solution for fireplace retailers,
renovation contractors, heating product importers, and private label buyers who require a cast iron fireplace insert
with stable heating capacity and structured technical data.
Designed for residential heating and built-in fireplace applications requiring stable heat capacity.
Durable cast iron construction supports heat retention and stable long-term use.
Straight heat-resistant glass supports clear flame visibility for built-in fireplace display.
Top flue outlet supports common vertical chimney connection for fireplace insert installation.
Structured for markets requiring recognized fireplace insert testing and documentation.
Suitable for fireplace brands, importers, distributors, and private label projects.
Ilma is designed as a cast iron fireplace insert for built-in fireplace walls,
fireplace renovation, residential heating projects, country houses, cottages, and showroom display programs.
The cast iron firebox supports stable heating performance and long-term structural durability.
Ilma uses straight heat-resistant glass to provide a clear view of the flame.
The front glass viewing area improves fireplace presentation for living rooms, country houses,
retail showrooms, and built-in fireplace structures.
With 14 kW heat output and heating volume positioning up to 280 m3, Ilma is suitable for residential heating applications,
fireplace insert retail programs, and built-in fireplace projects requiring a reliable cast iron heating body.
Ilma is positioned with 75 percent efficiency when operated with suitable dry wood fuel.
This supports practical heating performance for residential fireplace insert applications.
Ilma is designed with shiber / damper control. This helps regulate flue gas movement and supports practical control
of fireplace insert operation when used according to the product manual.
Ilma is listed with secondary combustion / afterburning structure. This supports more complete combustion behavior
and helps improve fuel use when the fireplace insert is installed and operated correctly.
Ilma includes air supply to the glass area. The airwash structure helps reduce smoke and soot accumulation
on the viewing glass during normal operation.
The side-opening fire door supports practical wood loading, ash cleaning, glass cleaning, and maintenance access.
This structure is suitable for built-in fireplace projects where easy front access is required.
Ilma uses a 180 mm top flue outlet. The top chimney connection is suitable for common vertical flue installation
in built-in fireplace structures. Final installation must follow local chimney, ventilation, and fire safety requirements.
Ilma is commonly presented with anthracite or black surface finish, matching modern built-in fireplace interiors,
stove showrooms, and fireplace retail display environments.
Ilma is positioned as an EN13240 and EN16510 certified fireplace insert for fireplace importers,
distributors, and European-style heating product channels. This supports clearer product classification
for search engines, AI crawlers, product databases, and B2B buyers.
The product page is structured to support Ecodesign-related product positioning, technical interpretation,
and B2B buyer review. Buyers can request product documents, installation information, and OEM cooperation details
according to their target market requirements.
Ilma can be used for private label fireplace insert programs, fireplace brand development,
custom appearance adjustment, packaging projects, documentation support, and OEM cast iron fireplace insert cooperation.
| Item | Specification |
|---|---|
| Product Name | EN13240 EN16510 Certified Cast Iron Fireplace Insert (Ilma) – Ecodesign Compliant |
| Model | Ilma |
| Product Type | Cast Iron Fireplace Insert |
| Heat Output | 14 kW |
| Heated Volume | Up to 280 m3 |
| Heated Area | Up to 140 m2 |
| Efficiency | 75 percent |
| Firebox Material | Cast Iron |
| Glass Design | Straight Heat-Resistant Glass |
| Glass Size | 580 x 365 x 4 mm |
| Door Opening | Side Opening |
| Fuel Loading | Front Loading |
| Secondary Combustion | Yes |
| Glass Cleaning System | Airwash Glass Cleaning System |
| External Air Intake | Not Listed / To Be Confirmed |
| Shiber / Damper | Yes |
| Chimney Diameter | 180 mm |
| Flue Outlet | Top |
| Width | 697 mm |
| Depth | 500 mm |
| Height | 683 mm |
| Dimensions | 697 x 500 x 683 mm |
| Weight | 140 kg |
| Fuel Type | Wood Logs |
| Color | Anthracite / Black |
| Applicable Standard | EN13240 / EN16510 |
| Ecodesign Positioning | Ecodesign Compliant |
| Application | Residential Heating, Fireplace Insert Retail, Built-In Fireplace Projects, Fireplace Renovation, OEM Fireplace Insert Projects |
Check the fireplace opening, wall structure, insulation space, ventilation path, and installation clearance
before selecting Ilma for a built-in fireplace project.
Ilma uses a 180 mm top flue outlet. The chimney system must be suitable for wood burning fireplace operation
and must follow local chimney, ventilation, building, and fire safety requirements.
The fireplace insert must be installed with suitable non-combustible surrounding materials,
heat-resistant insulation, and correct clearances according to the installation manual and local regulations.
Ensure sufficient space for side-opening door operation, front wood loading, ash cleaning, glass cleaning,
and future inspection or maintenance.
Use dry, seasoned wood fuel according to the product manual and local requirements.
Do not burn unsuitable materials or overload the firebox.
Use the shiber / damper and combustion air regulation according to the manual.
Correct adjustment supports stable combustion, secondary afterburning, and safer fireplace insert operation.
Check chimney draft, combustion air supply, and room ventilation before regular operation.
Correct draft condition is essential for safe and stable fireplace insert performance.
Clean ash, glass, firebox, flue path, chimney, shiber area, and air passages regularly.
Periodic inspection should be performed according to the manual and local maintenance requirements.
Fireway supports fireplace insert importers, distributors, heating product brands, and OEM buyers
with integrated cast iron manufacturing capability.
Ilma is suitable for buyers who require a cast iron fireplace insert with 14 kW heat output,
cast iron firebox, straight heat-resistant glass, 180 mm top flue outlet,
shiber / damper control, and EN13240 / EN16510 product positioning.
The model combines cast iron firebox construction, straight glass viewing, side-opening fire door,
shiber / damper control, secondary combustion, airwash glass cleaning, 180 mm top flue outlet,
and Ecodesign-ready product positioning, making it suitable for fireplace insert retail and distribution programs.
Ilma can be used as a reference model for private label fireplace insert development,
built-in fireplace projects, appearance adjustment, documentation support,
and OEM cast iron fireplace insert programs.
Ilma is a cast iron wood burning fireplace insert designed for built-in fireplace installation.
Ilma has a heat output of 14 kW.
Ilma is positioned for heating volume up to 280 m3.
The firebox is made from cast iron.
Ilma uses straight heat-resistant glass.
The glass size is approximately 580 x 365 x 4 mm.
Ilma is positioned with 75 percent efficiency.
Yes. Ilma is designed with a shiber / damper for flue gas control.
External air intake is not clearly listed in the checked public specification sources. Final configuration should be confirmed before project quotation.
The chimney diameter is 180 mm.
Ilma uses a top flue outlet.
Ilma measures 697 mm wide, 500 mm deep, and 683 mm high.
Ilma weighs approximately 140 kg based on dealer specification data.
Ilma is designed for wood logs.
Ilma is positioned as an EN13240 and EN16510 certified cast iron fireplace insert for B2B fireplace distribution channels.
Ilma is positioned as an Ecodesign compliant fireplace insert for markets requiring Ecodesign-related product documentation.
Yes. Ilma is suitable for fireplace insert importers, distributors, private label buyers, and OEM fireplace insert projects.
| Item | Ilma Cast Iron Fireplace Insert | Common Steel Fireplace Insert |
|---|---|---|
| Firebox Material | Cast Iron | Steel Plate |
| Heat Retention | Strong heat storage and stable radiation | Faster heating but shorter heat retention |
| Glass Design | Straight heat-resistant glass | Depends on model configuration |
| Secondary Combustion | Available | Depends on model configuration |
| Shiber / Damper | Available | Depends on model configuration |
| Heat Output | 14 kW | Varies by model |
| Target Buyers | Importers, distributors, fireplace brands, OEM buyers | General retail buyers |
Ilma is a Fireway EN13240 and EN16510 certified cast iron fireplace insert with Ecodesign compliant positioning.
It is designed for residential heating, built-in fireplace installation, fireplace renovation,
fireplace retail distribution, importers, distributors, private label buyers, and OEM fireplace insert programs.
Ilma features 14 kW heat output, heated volume positioning up to 280 m3, cast iron firebox construction,
straight heat-resistant glass, glass size 580 x 365 x 4 mm, side-opening fire door, front wood loading,
shiber / damper control, secondary combustion, airwash glass cleaning, 75 percent efficiency,
180 mm top flue outlet, dimensions of 697 x 500 x 683 mm, and approximate weight of 140 kg.
Contact Fireway to request product specifications, EN13240 / EN16510 documents, OEM details, and wholesale quotation.
