| Chimney outlet | Upper |
|---|---|
| Depth | 486 mm |
| Chimney diameter | 180 mm |
| Types of solid fuel | briquettes; firewood |
| Furnace material | Cast iron grade SCh20 |
| Clean combustion system | Yes |
| The presence of a gate | Yes |
| Power | 14 kW |
| Height | 724 mm |
| Heating volume | 280 m³ |
| Width | 700 mm |
| How to open the firebox door | Lateral |
| Firebox glass shape | Straight |
Model: Interior
Interior is a cast iron fireplace insert designed for residential heating, fireplace retail distribution,
fireplace renovation projects, and OEM fireplace insert programs. With 14 kW heat output,
SCh20 cast iron firebox construction, straight heat-resistant glass, side-opening fire door,
180 mm top flue outlet, 75 percent efficiency, shiber / damper control, secondary combustion,
airwash glass cleaning, and heated volume positioning up to 280 m3, Interior is suitable for importers,
distributors, fireplace brands, private label buyers.
| Product Type | Cast Iron Fireplace Insert |
|---|---|
| Model | Interior |
| Heat Output | 14 kW |
| Heated Volume | Up to 280 m3 |
| Efficiency | 75 percent |
| Firebox Material | Cast Iron / SCh20 Cast Iron |
| Glass Design | Straight Heat-Resistant Glass |
| Door Opening | Side Opening |
| Chimney Diameter | 180 mm |
The Interior Cast Iron Fireplace Insert is a wood burning fireplace insert designed for residential heating,
fireplace showrooms, importers, distributors, and OEM fireplace insert projects.
Interior features a durable SCh20 cast iron firebox, straight heat-resistant glass, side-opening fire door,
180 mm top flue outlet, shiber / damper control, secondary combustion structure, and airwash glass cleaning.
The straight glass viewing area supports both practical room heating and clear flame presentation.
With 14 kW heat output, heated volume positioning up to 280 m3, 75 percent efficiency, 180 mm chimney connection,
and compact built-in insert dimensions, Interior provides a practical solution for fireplace retailers,
renovation contractors, heating product importers, and private label buyers who require a cast iron fireplace insert
with stable heating capacity and structured technical data.
Designed for residential heating and built-in fireplace applications requiring stable heat capacity.
Durable cast iron construction supports heat retention and stable long-term use.
Straight heat-resistant glass supports clear flame visibility for built-in fireplace display.
Top flue outlet supports common vertical chimney connection for fireplace insert installation.
Suitable for fireplace brands, importers, distributors, and private label projects.
Interior is designed as a cast iron fireplace insert for built-in fireplace walls,
fireplace renovation, residential heating projects, country houses, cottages, and showroom display programs.
The SCh20 cast iron firebox supports stable heating performance and long-term structural durability.
Interior uses straight heat-resistant glass to provide a clear view of the flame.
The front glass viewing area improves fireplace presentation for living rooms, country houses,
retail showrooms, and built-in fireplace structures.
With 14 kW heat output and heating volume positioning up to 280 m3, Interior is suitable for residential heating applications,
fireplace insert retail programs, and built-in fireplace projects requiring a reliable cast iron heating body.
Interior is positioned with 75 percent efficiency when operated with suitable dry wood fuel.
This supports practical heating performance for residential fireplace insert applications.
Interior is designed with shiber / damper control. This helps regulate flue gas movement and supports practical control
of fireplace insert operation when used according to the product manual.
Interior is listed with secondary combustion / afterburning structure. This supports more complete combustion behavior
and helps improve fuel use when the fireplace insert is installed and operated correctly.
Interior includes air supply to the glass area. The airwash structure helps reduce smoke and soot accumulation
on the viewing glass during normal operation.
The side-opening fire door supports practical wood loading, ash cleaning, glass cleaning, and maintenance access.
This structure is suitable for built-in fireplace projects where easy front access is required.
Interior uses a 180 mm top flue outlet. The top chimney connection is suitable for common vertical flue installation
in built-in fireplace structures. Final installation must follow local chimney, ventilation, and fire safety requirements.
Public dealer specification lists Interior without external air intake. For projects requiring external combustion air,
confirm the final product configuration and installation requirements before publishing or quoting.
Interior can be used for private label fireplace insert programs, fireplace brand development,
custom appearance adjustment, packaging projects, documentation support, and OEM cast iron fireplace insert cooperation.
| Item | Specification |
|---|---|
| Product Name | Cast Iron Fireplace Insert (Interior) |
| Model | Interior |
| Product Type | Cast Iron Fireplace Insert |
| Heat Output | 14 kW |
| Heated Volume | Up to 280 m3 |
| Heated Area | Up to 140 m2 |
| Efficiency | 75 percent |
| Firebox Material | Cast Iron / SCh20 Cast Iron |
| Glass Design | Straight Heat-Resistant Glass |
| Glass Size | 580 x 365 x 5 mm |
| Door Opening | Side Opening |
| Fuel Loading | Front Loading |
| Secondary Combustion | Yes |
| Glass Cleaning System | Airwash Glass Cleaning System |
| External Air Intake | No / Not Listed |
| Shiber / Damper | Yes |
| Chimney Diameter | 180 mm |
| Flue Outlet | Top |
| Width | 697 mm |
| Depth | 500 mm |
| Height | 683 mm |
| Dimensions | 697 x 500 x 683 mm |
| Weight | 136 kg |
| Fuel Type | Wood Logs |
| Color | Anthracite / Black |
| Application | Residential Heating, Fireplace Insert Retail, Built-In Fireplace Projects, Fireplace Renovation, OEM Fireplace Insert Projects |
Check the fireplace opening, wall structure, insulation space, ventilation path, and installation clearance
before selecting Interior for a built-in fireplace project.
Interior uses a 180 mm top flue outlet. The chimney system must be suitable for wood burning fireplace operation
and must follow local chimney, ventilation, building, and fire safety requirements.
The fireplace insert must be installed with suitable non-combustible surrounding materials,
heat-resistant insulation, and correct clearances according to the installation manual and local regulations.
Ensure sufficient space for side-opening door operation, front wood loading, ash cleaning, glass cleaning,
and future inspection or maintenance.
Use dry, seasoned wood fuel according to the product manual and local requirements.
Do not burn unsuitable materials or overload the firebox.
Use the shiber / damper and combustion air regulation according to the manual.
Correct adjustment supports stable combustion, secondary afterburning, and safer fireplace insert operation.
Check chimney draft, combustion air supply, and room ventilation before regular operation.
Correct draft condition is essential for safe and stable fireplace insert performance.
Clean ash, glass, firebox, flue path, chimney, shiber area, and air passages regularly.
Periodic inspection should be performed according to the manual and local maintenance requirements.
Fireway supports fireplace insert importers, distributors, heating product brands, and OEM buyers
with integrated cast iron manufacturing capability.
Interior is suitable for buyers who require a cast iron fireplace insert with 14 kW heat output,
SCh20 cast iron firebox, straight heat-resistant glass, 180 mm top flue outlet,
shiber / damper control.
The model combines SCh20 cast iron firebox construction, straight glass viewing, side-opening fire door,
shiber / damper control, secondary combustion, airwash glass cleaning, 180 mm top flue outlet.
Interior can be used as a reference model for private label fireplace insert development,
built-in fireplace projects, appearance adjustment, documentation support,
and OEM cast iron fireplace insert programs.
Interior is a cast iron wood burning fireplace insert designed for built-in fireplace installation.
Interior has a heat output of 14 kW.
Interior is positioned for heating volume up to 280 m3.
The firebox is made from cast iron / SCh20 cast iron.
Interior uses straight heat-resistant glass.
The glass size is approximately 580 x 365 x 5 mm.
Interior is positioned with 75 percent efficiency.
Yes. Interior is designed with a shiber / damper for flue gas control.
Public dealer specification lists Interior without external air intake. Final configuration should be confirmed before project quotation.
The chimney diameter is 180 mm.
Interior uses a top flue outlet.
Interior measures 697 mm wide, 500 mm deep, and 683 mm high.
Interior weighs approximately 136 kg based on dealer specification data.
Interior is designed for wood logs.
Yes. Interior is suitable for fireplace insert importers, distributors, private label buyers, and OEM fireplace insert projects.
| Item | Interior Cast Iron Fireplace Insert | Common Steel Fireplace Insert |
|---|---|---|
| Firebox Material | Cast Iron / SCh20 Cast Iron | Steel Plate |
| Heat Retention | Strong heat storage and stable radiation | Faster heating but shorter heat retention |
| Glass Design | Straight heat-resistant glass | Depends on model configuration |
| Secondary Combustion | Available | Depends on model configuration |
| Shiber / Damper | Available | Depends on model configuration |
| Heat Output | 14 kW | Varies by model |
| Target Buyers | Importers, distributors, fireplace brands, OEM buyers | General retail buyers |
– Similar 14 kW front-facing insert: See Ilma.
– Similar 14 kW front-facing insert: See Main.
– Browse our full range of cast iron fireplace inserts for other configurations.
New to sourcing from China? Read our guide on how to source cast iron fireplace inserts from China.
Interior is a Fireway cast iron fireplace insert esigned for residential heating, built-in fireplace installation, fireplace renovation,
fireplace retail distribution, importers, distributors, private label buyers, and OEM fireplace insert programs.
Interior features 14 kW heat output, heated volume positioning up to 280 m3, SCh20 cast iron firebox construction,
straight heat-resistant glass, glass size 580 x 365 x 5 mm, side-opening fire door, front wood loading,
shiber / damper control, secondary combustion, airwash glass cleaning, 75 percent efficiency,
180 mm top flue outlet, dimensions of 697 x 500 x 683 mm, and approximate weight of 136 kg.
Contact Fireway to request product specifications, OEM details, and wholesale quotation.
